YC-A-GN-0002 | GNSS Survey Antenna (Standard/Integrated Configurations)
Price on request
Request a quoteMulti-constellation GNSS antenna for geodetic surveying, construction and deformation monitoring. Available in standard survey and communications-integrated configurations with different connectors, housings and electrical specifications.
The image shows the standard survey configuration; the communications-integrated version has a different housing.
Standard survey configuration
| Receive bands | GPS L1/L2/L5; GLONASS G1/G2/G3; BDS B1I/B1C/B2a/B2b/B3I; Galileo E1/E5a/E5b/E6 |
|---|---|
| Peak antenna gain | 5.5 dBi |
| Phase-center specification | ±2 mm |
| LNA gain | 40 ±2 dB |
| Noise figure | ≤1.5 dB |
| Dimensions | Φ152 × 63.7 mm |
| Weight | ≤450 g |
| Connector | TNC-K |
Communications-integrated configuration
| Receive bands | GPS L1/L2/L5; GLONASS G1/G2/G3; BDS B1I/B1C/B2a/B2b/B3I; Galileo E1/E5a/E5b/E6; 4G; Bluetooth; V2X; L-BAND |
|---|---|
| Peak antenna gain | GNSS: 5.5 dBi; 4G: 2 dBi; Wi-Fi/BT: 1.5 dBi; V2X: 1.0 dBi |
| Phase-center specification | ±2 mm |
| LNA gain | 40 ±2 dB (GNSS) |
| Noise figure | ≤2.0 dB (GNSS) |
| Operating current | ≤100 mA |
| Dimensions | Φ136 × 23.6 mm |
| Weight | ≤190 g |
| Connector | MCX-JW |
Selection and installation
The two configurations have different connectors and housings. Select according to receiver interface, installation space and cable needs. Please include power and ingress-protection requirements in your inquiry.
Specific 4G, Wi-Fi/Bluetooth and V2X bands, ports and receiver compatibility require review. A modem or GNSS receiver is not implied to be included. The phase-center value is not a positioning-accuracy guarantee.
Procurement and customization
- Standard MOQ: 1 unit
- Typical sample lead time: 2 weeks
- Typical volume-production lead time: 4 weeks
Final specifications, accessories, quantity, price and delivery are subject to technical review and quotation.
