| Motor count | 6 |
|---|
| Alignment method | Precision core, cladding and manual alignment |
|---|
| Supported fibres | ITU-T G.651, G.652, G.653, G.654.E, G.655, G.657; bare fibres, drop cables, patch cords and invisible fibres |
|---|
| Average splice loss (typical) | 0.015 dB (G.652); 0.01 dB (G.651); 0.04 dB (G.653); 0.02 dB (G.654.E); 0.03 dB (G.655); 0.02 dB (G.657) |
|---|
| Splice time | ≤6 s (SM FAST mode); ≤16 s (AUTO mode) |
|---|
| Heating time | 10 s (60 mm thin heat-shrink sleeve) |
|---|
| Fibre diameters | Cladding: 80–150 μm; coating: 0.1–3 mm |
|---|
| Cleave length | 5–16 mm |
|---|
| Splice programs | 300 programs |
|---|
| Heating programs | 100 programs |
|---|
| Electrode life | 5000 cycles; user-replaceable |
|---|
| Battery capacity and operating cycles | 10000 mAh; typically 400 splice-and-heat cycles per charge |
|---|
| Battery service life | 300–500 recharge cycles; user-replaceable |
|---|
| Fibre-image magnification | Dual view: 150×; single X/Y view: up to 600× |
|---|
| Attenuation splicing | 0.1–15 dB; 0.1 dB steps |
|---|
| Heat-shrink sleeves | 60 mm, 40 mm and a range of heat-shrink sleeves |
|---|
| Splice records | 30000 records; 200 latest images |
|---|
| Display | 5-inch capacitive touchscreen |
|---|
| Fibre tension test | Approximately 2 N |
|---|
| Work illumination | Built-in high-brightness, wide-area lamp |
|---|
| Operating environment | Temperature: −20–+50 °C; humidity: 0–95% RH; altitude: 0–6000 m; maximum wind speed: 15 m/s |
|---|
| Drop conditions | Operates normally after drops from 76 cm onto 5 faces, excluding the wind-cover face |
|---|
| Water resistance | IPX2; usable for 10 min under rainfall of 10 mm/h |
|---|
| Dust resistance | IP5X; exposure to dust containing 0.1–500 μm aluminium-silicate particles |
|---|
| User interface | Graphical user interface (GUI) |
|---|
| Maximum power consumption | 80 W |
|---|
| External power supply | AC: 100–240 V, 50/60 Hz, 0–1.5 A; DC: 13–14 V |
|---|
| External interfaces | USB; USB 2.0 Mini; Mini DIN 6 pin |
|---|
| Dimensions (W × H × D) | (145±3) × (170±3) × (165±3) mm; including rubber parts |
|---|
| Weight | (2.6±0.1) kg; including battery |
|---|
