YC-TI-SA-0002 | 4052 Series Signal/Spectrum Analyzer
Price on request
Request a quoteTest & measurement instruments
The 4052 Series Signal/Spectrum Analyzer supports RF measurements, wideband signal analysis and wireless communications testing. Frequency range, analysis bandwidth and software capabilities depend on the selected model and options.
Key specifications
| Series frequency coverage | 2 Hz–50 GHz (model-dependent) |
|---|---|
| Analysis bandwidth | 10 MHz standard; 40, 200, 400, 600 MHz or 1.2 GHz optional |
| Phase noise | Typically better than −124 dBc/Hz (1 GHz carrier, 10 kHz offset); typically better than −129 dBc/Hz with the phase-noise enhancement option |
| Display | 11.6-inch touchscreen |
| Analysis functions | Spectrum, I/Q and vector signal analysis; real-time spectrum and wireless communications analysis depend on options |
Series-level information. Confirm the frequency range, bandwidth, interfaces and software functions for the selected model and options.
Reseller product. Contact Yanchuan to confirm configuration, quotation and lead time.
